Official data verified
DS-UPS600(O-STD)/EU
Hikvision
Contact support for the sales price
UPS capacity
600 VA / 360 W
Input voltage range
140 VAC to 290 VAC
Input frequency
50/60 Hz self-adaptive
Official data verified
Official specifications
- Product
- Uninterruptible Power Supply
- Model
- DS-UPS600
- UPS capacity
- 600 VA / 360 W
- Input voltage range
- 140 VAC to 290 VAC
- Input frequency
- 50/60 Hz self-adaptive
- Input plug
- Schuko
- Output voltage range
- 210 VAC to 235 VAC
- Output frequency
- 50/60 Hz ± 0.5 Hz self-adaptive
- Transfer time
- ≤ 10 ms
- Waveform
- PWM
- Output outlet
- Universal
- Outlet quantity
- 2
- Battery type
- 12 V/7 Ah lead-acid battery
- Recharge time
- 4-6 hours to recover 90% capacity
- Typical backup time
- 60 W: 35 min; 100 W: 20 min; 200 W: 3 min
- Communication port
- None
- Full protection
- Surge, overload, discharge and overcharge protection
- Operating Temperature
- 0 °C to 40 °C
- Operating Humidity
- 30% to 90% non-condensing
- Dimensions
- 274 mm × 95 mm × 139 mm
- Weight
- Approx. 4.2 kg
